Overflow Type Ball Mill
Feed particle size95-3400(kW).
Processing capacity0-170tph.
Applicable materialwidely used in powder-making production line which include silicate, new-type building material, cement, refractory material, fertilizer, glass ceramics and so on..
Transport Package:Standard Packing,Seaworthy Packing,or as Require
you can contact us.
The Overflow Type Ball Mill is a high-end equipment. It is generally used as a core equipment in the beneficiation production line. Its main function is grinding. Its main advantage is high grinding precision and large production capacity. Such equipment can be better used by users. The economic benefits created for users are also quite amazing. This article describes the device in detail based on the working principle and characteristics of the device.
Grinding steel ball
Lining plate
Consignment
1.High efficiency and low invest with high return.
2.Even product size that means the shape of the final products is circular.
3.Easy operation and easy maintenance.
4.Good stability and low energy consumption.
5.Adjustable device.
6.No pollution and low noise.
Parameters
| Model | Cylinder diameter(mm) |
Cylinder length(mm) |
Effective volume(m³) |
Speed(r/min) | Ball load(t) |
Motor | Weight(t） | |
| Power(kW) | Revolution(r/min) | |||||||
| MQY15x30 | 1500 | 3000 | 5 | 26.6 | 9 | 95 | 742 | 18.5 |
| MQY21x30 | 2100 | 3000 | 9.4 | 22.1 | 15 | 200 | 740 | 45 |
| MQY24x30 | 2400 | 3000 | 12.2 | 21 | 22.5 | 250 | 980 | 55 |
| MQY27x36 | 2700 | 3600 | 18.5 | 20.5 | 39 | 400 | 187.5 | 61.34 |
| MQY27x45 | 2700 | 4500 | 23.5 | 20.5 | 43.5 | 500 | 187.5 | 76 |
| MQY28x80 | 2800 | 8000 | 43 | 20 | 78.6 | 800 | 137 | 115 |
| MQY32x36 | 3200 | 3600 | 26.3 | 18.3 | 48.4 | 500 | 16.7 | 116.94 |
| MQY32x45 | 3200 | 4500 | 32.9 | 18.3 | 60.5 | 630 | 167 | 124.23 |
| MQY32x75 | 3200 | 7500 | 55.5 | 18.3 | 102 | 1250 | 734 | 154 |
| MQY34x45 | 3400 | 4500 | 37 | 18.4 | 74.6 | 800 | 167 | 129.8 |
| MQY34x56 | 3400 | 5600 | 45.8 | 17.9 | 84.3 | 1120 | 985 | |
| MQY36x50 | 3600 | 5000 | 46.7 | 17.5 | 102 | 1250 | 167 | 150 |
| MQY36x60 | 3600 | 6000 | 54 | 17.3 | 102 | 1250 | 167 | 162.7 |
| MQY36x90 | 3600 | 9000 | 83.5 | 17.4 | 138 | 1800 | 734 | 286 |
| MQY40x60 | 4000 | 6000 | 69.8 | 16 | 126 | 1500 | 200 | 203.5 |
| MQY40x135 | 4000 | 13500 | 155 | 16 | 233 | 3300 | 200 | 343 |
| MQY43x61 | 4300 | 6100 | 80 | 15.67 | 144 | 1750 | 200 | 215.3 |
| MQY55x65 | 5500 | 6500 | 143.3 | 13.8 | 264 | 3400 | 200 | 451.5 |
Principle
The main bearing is a key component of the Overflow Type Ball Mill. It must pay full attention to its lubrication. It is generally concentrated and lubricated with thin oil. The oil flows through the pump into four parts and is pressed into the main bearing and the transmission bearing, and then discharged to the bottom of the bearing. The pipe then flows back to the tank. For medium and small ball mills, oil ring automatic lubrication, oil cup oil lubrication or solid lubricants are used. Some concentrators are equipped with an automatic oil-breaking alarm device to ensure the reliability of lubrication. The overflow ball mill is supported on the main bearing by a hollow shaft at both ends. One of the two hollow shafts is axially stretchable on the main bearing and the other is fixed. Since the gearing of the ball mill produces a directional force, a hollow journal is designed with two shoulders, and the distance between the shoulders is exactly equal to the length of the bearing bush to prevent axial movement. The other hollow journal has no shoulders and its length is greater than 5-25 mm for the length of the bearing bush. When the cylinder is heated to elongate or the cylinder is flexed due to the load, it can freely expand and contract within a certain range.
