Tracked mobile crusher

Feed particle size800mm.

Processing capacity85-650t/h.

Applicable materialRiver pebble, limestone, granite, basalt, diabase, andesite, and various ore materials, construction waste, industrial solid waste, concrete aggregate, etc..

Transport Package:Standard Packing,Seaworthy Packing,or as Require

We will provide you with the best quality service.If you are interested in our product,
you can contact us.

jackerhuayi@gmail.com Send Enquiry

Overview
Parameters
Send Enquiry

Tracked mobile crusher is a kind of high efficiency crushing equipment. It is a kind of mining machinery equipment that crushes materials in different stages and sieves them according to certain discharge specifications. The equipment adopts self-driving mode, advanced technology and complete functions. Under any topographic conditions, it can reach any position of the work site. It should be widely used in metallurgy, construction, chemical industry, railway, water conservancy and other industries which often need to be relocated.

Tracked Mobile Crusher Features:

1. The chassis adopts steel ship structure with high strength and it is highly adaptable to different working sites
2. The well-known brand motor achieves the good performance of the power system, with features of low noise and energy saving, etc
3. According to different requirements of customers, we can provide the different crushing and screening equipment and combined type optimum design, and we fully guarantee the quality
4. The generator set can be equipped, work normally under complex situations, such as the situation of no power or sudden power off, ensuring continuous operation and reducing unnecessary loss

Parameters

Tracked jaw mobile crusher

type	CFTC-PE96	CFTC-PE106
hopper capacity	3m³	5m³
Feeder	GZDT9538	GZDT1145
Track	500×3.8m	500×3.8m
Walking speed	0-20m/min	0-20m/min
Climbing ability	±20°	±20°
power	96kw	106kw
Total power	112.9kw	141.4kw
shape	13m×2.8m×3.5m	14.4m×3m×3.6m
weight	38t	50t
capacity	300tph	450tph

Tracked Impact mobile crusher

type	CFTC-PF1110	CFTC-PF1213
hopper capacity	3m³	4m³
Feeder	GZDT9538	GZDT1145
Track	500m×3.8m	500m×4.2m
Walking speed	0-20m/min	0-20m/min
Climbing ability	±20°	±20°
power	96kw	106kw
Total power	196.8kw	250.8kw
shape	17m×3.5m×4m	18.5m×3.6m×4.1m
weight	40t	52t
capacity	100-250tph	160-400tph

Tracked cone mobile crusher

type	CFTC-CS160	CFTC-CS250	CFTC-CS300
hopper capacity	3m³	3m³	3m³
Track	500×3.8m	500×4.2m	500×4.2m
Walking speed	0-20m/min	0-20m/min	0-20m/min
Climbing ability	±20°	±20°	±20°
power	96kw	106kw	106kw
Total power	201kw	298.5kw	268.5kw
shape	17m×4m×5m	19m×4.3m×5.5m	19m×4.3m×5.5m
weight	40t	53t	52t
capacity	100-250tph	180-450tph	160-400tph

Principle

Working Principle of Tracked mobile crusher:
Material from the feed hopper into the crushing link of the machine, in the impeller of the crushing equipment is rapidly accelerated, its acceleration can reach hundreds of times the acceleration of gravity, after multiple probability impact, friction and grinding crushing. The broken material is discharged from the lower discharge port. With further cleaning in the screening process, the materials that meet the requirements are finished products. Of course, the whole processing process also needs the assistance of feeding.
