Portable Mobile jaw crusher

Feed particle size≤300mm.

Processing capacity1-100t/h..

Applicable materialConstruction waste, reinforced concrete, pebbles, granite, basalt, iron ore, limestone, quartz, diabase..

Transport Package:Standard Packing,Seaworthy Packing,or as Require

We will provide you with the best quality service.If you are interested in our product,
you can contact us.

jackerhuayi@gmail.com Send Enquiry

Overview
Parameters
Send Enquiry

The stone jaw crusher/rock jaw crusher's largest compression resistance is 320MPa.This series is complete in specifications and the first choice of primary crushing equipment. Its structure iseasy and solid. It is easy to maintain and enjoys satisfactory performance. The jaw crusher is widely used in the industries of mining, metallurgy, building, highway, railway, water conservancy and chemical.

Features of Portable Mobile jaw crusher:
1.Deep crushing cavity, high capacity;
2.High crushing ratio, homogeneous particle size;
3.Gasket adjusting device is reliable and convenient, large adjusting range and is more flexible;
4.Lubrication system is safe, parts are easy to change, it's easy to maintain;
5.Simple structure, low cost.
6.Energy saving: single machine saves 15%-30%, the whole system doubles.
7.Wide adjustment range of discharging port meets different customers' demands.
8.Low noise and little dust.

Parameters

Model	FeedingSize (mm)	DischargingSize (mm)	Capacity (t/h)	PowerforDieselengine (kw)	Weight (kg)	OverallDimension (mm)
PEC1525	<125	10-40	1-3	5.7	920	1836×1030×1408
PEC2540	<200	20-50	5-20	15.5	3150	2805×1210×1860
PEC4060	<500	40-100	20-50	30	3500	3030×1730×1930

Principle

The belt and belt pulley are driven by a motor, and the movable jaw moves up and down via eccentric shaft. The angle between fixed jaw and movable jaw becomes smaller when the moving jaw runs down, then the materials are crushed into pieces. It becomes bigger when the movable jaw runs up. The movable jaw plate leaves the fixed jaw plate under the action of tension rod and spring , then the end products come out from the crushing cavity.
